Key Commercial Data
| Orderkey | 2316365 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 520 (C-6-2017) |
| GTIN | 4055626127378 |
| Weight per Piece (excluding packing) | 216.000 g |
| Custom tariff number | 85176200 |
| Country of origin | US (United States) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -40 °C … 85 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Permissible humidity (operation) | 95 % (non-condensing) |
| Altitude | 2000 m |
| Degree of protection | IP20 |
General
| Mounting position | On horizontal DIN rail NS 35 in acc. with EN 60715 |
|---|---|
| Assembly instructions | on standard DIN rail NS 35 in accordance with EN 60715 |
| Net weight | 216 g |
| Housing material | PA V0 |
| Color | gray |
| Degree of pollution | 2 |
| Overvoltage category | II |
Power supply
| Nominal supply voltage | 24 V DC |
|---|---|
| Supply voltage range | 18 V DC … 30 V DC |
| Max. current consumption | 60 mA |
| Connection method | COMBICON plug-in screw terminal block |
| Conductor cross section flexible max. | 2.50 mm² |
| Conductor cross section flexible min. | 0.20 mm² |
| Conductor cross section solid max. | 2.50 mm² |
| Conductor cross section solid min. | 0.20 mm² |
| Conductor cross section AWG max. | 12 |
| Conductor cross section AWG min. | 24 |
