Key Commercial Data
| Orderkey | 2902911 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4046356696739 |
| Weight per Piece (excluding packing) | 6,962.000 g |
| Custom tariff number | 85444290 |
| Country of origin | DE (Germany) |
General
| Nominal voltage UN | 30 V DC |
|---|---|
| Max. current carrying capacity per path | 500 mA (up to 55°C ambient temperature) |
| Max. conductor resistance | 0.16 Ω/m |
| Length of cable | 45 m |
| Single wire, cross section | 0.14 mm² |
| Single wire, cross section [AWG] | 26 |
| Conductor construction: Number of litz wires: | 7 |
| Single wire, material | Cu tin-plated |
| External diameter | 11 mm |
| Shielding | yes |
| Outer sheath, material | PVC |
| External sheath, color | gray RAL 7035 |
Environmental conditions
| Ambient temperature (operation) | -20 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
| Flame resistance | IEC 60332-3-22 |
Connector 1
| Connection name | Field level |
|---|---|
| Connection method | IDC/FLK socket strip |
| Number of connections | 4 |
| Number of positions | 14 |
| Pitch | 2.54 mm |
Connector 2
| Connection name | Controller level |
|---|---|
| Connection method | IDC/FLK socket strip |
| Number of connections | 1 |
| Number of positions | 50 |
| Pitch | 2.54 mm |
Supported controller
| Controller | YOKOGAWA CS3000 CentumVP |
|---|---|
| – suitable I/O card | ADV161 |
| ADV561 | |
| Controller | YOKOGAWA STARDOM |
| – suitable I/O card | NFDV161 |
| NFDV561 |
