Key Commercial Data
| Orderkey | 2903740 |
|---|---|
| Packing unit | 10 pc |
| GTIN | 4046356762021 |
| Weight per Piece (excluding packing) | 72.200 g |
| Custom tariff number | 85369010 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 55 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
General
| Max. perm. operating voltage | 25 V AC |
|---|---|
| 50 V DC | |
| Max. perm. current (per branch) | 2 A |
| Number of positions | 8 |
| Mounting position | any |
| Assembly instructions | In rows with zero spacing |
| Degree of protection | IP00 |
Connection data for connection 1
| Connection name | Field level |
|---|---|
| Connection in acc. with standard | IEC / EN |
| Connection method | Spring-cage connection |
| Stripping length | 7 mm |
| Conductor cross section solid | 0.2 mm² … 2.5 mm² |
| Conductor cross section flexible | 0.2 mm² … 1.5 mm² |
| Conductor cross section AWG | 24 … 14 |
| Number of positions | 10 |
Connection data for connection 2
| Connection name | Controller level |
|---|---|
| Connection method | M12-SAC socket |
| Number of positions | 8 |
| Note | Socket, 8-pos., A-coded |
