Key Commercial Data
| Orderkey | 2288642 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 175 (IF-2002) |
| GTIN | 4017918057121 |
| Weight per Piece (excluding packing) | 242.300 g |
| Custom tariff number | 85369010 |
| Country of origin | DE (Germany) |
General
| Max. perm. operating voltage | 60 V DC |
|---|---|
| Max. perm. current (per branch) | 1 A |
| Max. permissible current (separate power supply) | 2 A (per byte) |
| Number of positions | 50 |
| Status display | No |
| Mounting position | any |
Connection data for connection 1
| Connection name | Field level |
|---|---|
| Connection in acc. with standard | IEC / EN |
| Connection method | Screw connection |
| Stripping length | 8 mm |
| Screw thread | M3 |
| Conductor cross section solid | 0.2 mm² … 4 mm² |
| Conductor cross section flexible | 0.2 mm² … 2.5 mm² |
| Conductor cross section AWG | 24 … 12 |
| Number of positions | 50 |
Standards and Regulations
| Connection in acc. with standard | CUL |
|---|---|
| Standards/regulations | IEC 60664 |
| IEC 60664A | |
| DIN VDE 0110 | |
| DIN VDE 0160 (in parts) | |
| Degree of pollution | 2 |
| Overvoltage category | II |
