Key Commercial Data
| Orderkey | 2294500 |
|---|---|
| Packing unit | 2 pc |
| Catalog page | Page 514 (C-5-2017) |
| GTIN | 4017918129750 |
| Weight per Piece (excluding packing) | 198.470 g |
| Custom tariff number | 85369010 |
| Country of origin | DE (Germany) |
Note
| Type of note | Notes on operation |
|---|---|
| Note | For I/O cards 6ES7 421-1BL01-0AA0, 6ES7 422-1BL00-0AA0, and 6ES7 422-7BL00-0AB0: Thanks to the wire bridges that are supplied as standard, the input and output bytes are non-isolated. |
| Type of note | Notes on operation |
| Note | For I/O cards 6ES7 421-7BH01-0AB0 and 6ES7 421-7DH00-0AB0: Only operate in conjunction with VIP-2/SC/FLK50/S7/A-S400 (Order No. 2322359) or VIP-2/PT/FLK50/S7/A-S400 (Order No. 2904289). All wire bridges on the adapter must be disconnected. |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
General
| Max. permissible operating voltage | < 50 V AC |
|---|---|
| 60 V DC | |
| Max. permissible current | 1 A (per path) |
| 8 A (per connection, supply via separate power supply) | |
| Max. permissible total current | 2 A (per Byte, for supply via connector) |
| 8 A (during supply via a separate bridged power supply) | |
| Mounting position | any |
| Degree of protection | IP00 |
Connection data 2
| Connection name | Field level |
|---|---|
| Connection method | IDC/FLK pin strip |
| Number of connections | 1 |
| Number of positions | 50 |
| Pitch | 2.54 mm |
