Key Commercial Data
| Orderkey | 2907381 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 510 (C-5-2017) |
| GTIN | 4055626256511 |
| Weight per Piece (excluding packing) | 108.770 g |
| Custom tariff number | 85369010 |
| Country of origin | RO (Romania) |
Ambient conditions
| Ambient temperature (operation) | -25 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 70 °C |
General
| Max. permissible operating voltage | < 50 V DC |
|---|---|
| Max. permissible current | 1 A (per path) |
| Max. permissible total current | 3 A (per byte when supplying from the module side) |
| 12 A (When supplying via the front adapter) | |
| Nominal operating mode | 100% operating factor |
| Degree of protection | IP20 |
Connection data 1
| Connection name | Field level |
|---|---|
| Connection method | IDC/FLK pin strip |
| Number of connections | 4 |
| Number of positions | 14 |
| Channels which can be connected | 32 |
| Pitch | 2.54 mm |
Connection data 2
| Connection name | Field level |
|---|---|
| Connection method | IDC/FLK pin strip |
| Number of connections | 2 |
| Number of positions | 14 |
| Channels which can be connected | 16 |
| Pitch | 2.54 mm |
Connection data 3
| Connection name | Supply |
|---|---|
| Connection method | Screw connection |
| Stripping length | 10 mm |
| Conductor cross section solid | 0.25 mm² … 1.5 mm² (with ferrule) |
| 0.5 mm² … 2.5 mm² (without ferrule) | |
| Conductor cross section flexible | 0.25 mm² … 1.5 mm² (with ferrule) |
| 0.5 mm² … 2.5 mm² (without ferrule) | |
| Torque | 0.4 Nm |
