Key Commercial Data
| Orderkey | 2314749 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 506 (C-5-2017) |
| GTIN | 4046356155205 |
| Weight per Piece (excluding packing) | 57.100 g |
| Custom tariff number | 85369010 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
General
| Max. permissible operating voltage | < 50 V AC |
|---|---|
| 60 V DC | |
| Max. permissible current | 50 mA (per path) |
| 500 mA (per connection, supply via separate power supply) | |
| Mounting position | any |
| Nominal operating mode | 100% operating factor |
| Degree of protection | IP20 |
Connection data 1
| Connection name | Field level |
|---|---|
| Connection method | IDC/FLK pin strip |
| Number of connections | 1 |
| Number of positions | 16 |
| Pitch | 2.54 mm |
Connection data 2
| Connection name | Supply |
|---|---|
| Connection method | Screw connection |
| Conductor cross section solid | 0.14 mm² … 1.5 mm² |
| Conductor cross section flexible | 0.14 mm² … 1.5 mm² |
| Conductor cross section AWG | 26 … 16 |
Supported controller
| Controller | SIEMENS S7-300 / ET 200 M |
|---|---|
| – suitable I/O card | 6ES7 331-7KF02-0AB0 |
| 6ES7 331-7KB02-0AB0 | |
| 6ES7 331-7TF01-0AB0 |
