Key Commercial Data
| Orderkey | 2702653 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 407 (C-6-2017) |
| GTIN | 4055626259994 |
| Weight per Piece (excluding packing) | 451.100 g |
| Custom tariff number | 85176200 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Degree of protection | IP20 |
|---|---|
| Ambient temperature (operation) | -40 °C … 70 °C |
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Permissible humidity (operation) | 10 % … 95 % (non-condensing) |
| Permissible humidity (storage/transport) | 10 % … 95 % (non-condensing) |
| Air pressure (operation) | 53 kPa … 108 kPa (5000 m above sea level) |
| Air pressure (storage/transport) | 53 kPa … 108 kPa (5000 m above sea level) |
Interfaces
| Interface 1 | Ethernet (RJ45) |
|---|---|
| No. of ports | 4 (RJ45 ports) |
| Note on the connection method | Auto negotiation and autocrossing |
| Transmission physics | Copper |
| Transmission speed | 10/100/1000 Mbps |
| Transmission length | 100 m (per segment) |
| Signal LEDs | Data receive, link status |
| Interface 2 | SFP module |
| No. of ports | 2 (SFP ports) |
| Transmission physics | Depending on the SFP module |
| Transmission speed | 100/1000 Mbps (full duplex) |
| Transmission length | up to 80 km (Depending on the fiber/SFP module used) |
| Signal LEDs | Data receive, link status |
| Interface 3 | Ethernet (combo) |
| No. of ports | 2 (Combo ports) |
| Connection method | SFP or RJ45 ports |
| Note on the connection method | Auto negotiation and autocrossing |
| Transmission physics | Depending on the SFP module |
| Transmission speed | 10/100/1000 Mbps (full duplex) |
| Transmission length | up to 80 km (Depending on the fiber/SFP module used) |
| Signal LEDs | Data receive, link status |
Function
| Basic functions | Store-and-forward switch, complies with IEEE 802.3 |
|---|---|
| Management | Web-based management (HTTP/HTTPS) |
| SNMPv1/v2/v3 | |
| Command-line interface (Telnet, SSH) | |
| Diagnostic functions | RMON History |
| LLDP (Link Layer Discovery Protocol) | |
| SNMP-Traps | |
| N:1-Portmirroring | |
| ACD (Address Conflict Detection) | |
| Filter functions | Quality of Service (8 priority classes) |
| Port-Priorisierung | |
| VLAN (up to 32 VLANs) | |
| IGMP Snooping (32 groups) | |
| IGMP Query | |
| Auto-Query-Port | |
| Extended Multicast Filtering | |
| Redundancy | MRP (Media Redundancy Protocol) |
| RSTP (Rapid Spanning Tree Protocol) | |
| FRD (Fast Ring Detection) | |
| Large Tree Support | |
| MAC address table | 8k |
| IP parameterization | DHCP-Client |
| DHCP Option 82 (Relay Agent) | |
| DHCP server (pool-based, port-based) | |
| BootP | |
| PROFINET device function | PROFINET device |
| PROFINET conformance class | Conformance-Class B |
| Time synchronization | SNTP (Simple Network Time Protocol) |
| Status and diagnostic indicators | LEDs: US1, US2 (power supply), Fail (alarm contact), 2 LEDs per Ethernet port (Link/Activity and Speed) |
| Signal contact control voltage | 24 V DC (typical) |
| Signal contact control current | 200 mA (1 minute, maximum) |
