Key Commercial Data
| Orderkey | 2904577 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 347 (C-6-2017) |
| GTIN | 4046356864541 |
| Weight per Piece (excluding packing) | 114.000 g |
| Custom tariff number | 85369010 |
| Country of origin | DE (Germany) |
General
| Mounting position | any |
|---|---|
| Net weight | 114 g |
| Color | green |
| Degree of pollution | 2 |
| Overvoltage category | II |
Serial interface
| Interface 1 | Ethernet interface, 10/100Base-T(X) in acc. with IEEE 802.3u |
|---|---|
| No. of ports | 1 |
| Connection method | Spring-cage connection |
| Transmission length | 100 m (including patch cables) |
| Conductor cross section solid min. | 0.2 mm² |
| Conductor cross section solid max. | 1.5 mm² |
| Conductor cross section flexible min. | 0.2 mm² |
| Conductor cross section flexible max. | 1 mm² |
| Conductor cross section AWG min. | 24 |
| Conductor cross section AWG max. | 16 |
| Pin assignment | 1,2,3,6 |
| 4,5,7,8 | |
| Serial transmission speed | 10/100 Mbps |
| Interface 2 | Ethernet interface, 10/100Base-T(X) in acc. with IEEE 802.3u |
| No. of ports | 1 |
| Connection method | RJ45 CAT5e |
| Pin assignment | 1,2,3,6 |
| 1,2,3,6 |
Standards and Regulations
| Designation | Air clearances and creepage distances |
|---|---|
| Standards/regulations | DIN EN 50178 |
| Rated insulation voltage | 50 V |
| Rated surge voltage | 0.5 kV |
| Insulation | Basic insulation |
| Degree of pollution | 2 |
| Overvoltage category | II |
| Noxious gas test | ISA-S71.04-1985 G3 Harsh Group A |
