Key Commercial Data
| Orderkey | 2313164 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 289 (C-8-2015) |
| GTIN | 4046356477376 |
| Weight per Piece (excluding packing) | 230.000 g |
| Custom tariff number | 85176200 |
| Country of origin | DE (Germany) |
Ambient conditions
| Degree of protection | IP20 |
|---|---|
| Ambient temperature (operation) | -20 °C … 55 °C |
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Permissible humidity (operation) | 10 % … 95 % (non-condensing) |
| Permissible humidity (storage/transport) | 10 % … 95 % (non-condensing) |
Interfaces
| Interface 1 | Ethernet (RJ45) |
|---|---|
| No. of ports | 2 (RJ45 ports) |
| Note on the connection method | Auto negotiation and autocrossing |
| Transmission physics | Copper |
| Transmission speed | 10/100 Mbps |
| Transmission length | 100 m (per segment) |
| Interface 2 | POF/PCF |
| No. of ports | 2 (SC-RJ) |
| Transmission physics | POF-SCRJ |
| Transmission speed | 10/100 Mbps (full duplex) |
| Transmission length | up to 250 m (depending on the fiber used) |
Function
| Basic functions | Store-and-forward media converter standard-compliant IEEE 802.3 2, priority classes according to IEEE 802.1 P, TCP/IP protocol, BootP-compatible, port mirroring, integrated web server function, multicast filtering, IGMP snooping, VLAN, Rapid Spanning Tree (RSTP) |
|---|---|
| Redundancy | RSTP (Rapid Spanning Tree Protocol) |
| FRD (Fast Ring Detection) | |
| Large Tree Support | |
| Supported browsers | Internet Explorer 5.5 or higher |
| Status and diagnostic indicators | 2 status LEDs per Ethernet: activity and duplex mode, supply voltage US1and US2(redundant supply voltage) as well as LED BAR GRAPH for FO ports for displaying the system reserve for each optical interface. |
| Signal contact control voltage | 24 V |
Network expansion parameters
| Cascading depth | Line, star, tree and redundant ring; any cascading depth |
|---|---|
| Maximum conductor length (twisted pair) | 100 m |
