Key Commercial Data
| Orderkey | 2902856 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 337 (C-6-2017) |
| GTIN | 4046356689212 |
| Weight per Piece (excluding packing) | 174.400 g |
| Custom tariff number | 85176200 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -40 °C … 65 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Permissible humidity (operation) | 30 % … 95 % (non-condensing) |
| Permissible humidity (storage/transport) | 30 % … 95 % (non-condensing) |
| Altitude | 5000 m (For restrictions see manufacturer’s declaration) |
| 2000 m (With UL approval) | |
| Degree of protection | IP20 |
General
| Electrical isolation | according to IEEE 802.3 |
|---|---|
| VCC // FE // Ethernet | |
| Latency | ± 1.3 µs (Store&Forward mode, 10/100 Mbps, depending on the frame size) |
| Test voltage data interface/power supply | 1.5 kVrms(50 Hz, 1 min.) |
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
| Net weight | 174.4 g |
| Housing material | PA 6.6-FR |
| Color | green |
| MTBF | 284 Years (Telcordia standard, 25°C temperature, 21% operating cycle (5 days a week, 8 hours a day)) |
| 74 Years (Telcordia standard, 40°C temperature, 34.25% operating cycle (5 days a week, 12 hours a day)) | |
| MTTF | 1400 Years (SN 29500 standard, temperature 25 °C, operating cycle 21 % (5 days a week, 8 hours a day)) |
| 599 Years (SN 29500 standard, temperature 40 °C, operating cycle 34.25 % (5 days a week, 12 hours a day)) | |
| 101 Years (SN 29500 standard, temperature 40 °C, operating cycle 100 % (7 days a week, 24 hours a day)) | |
| Conformance | CE-compliant |
| ATEX | II 3 G Ex nA IIC T4 Gc X (Please follow the special installation instructions in the documentation!) |
| UL, USA/Canada | cULus listed UL 508 |
| Class I, Zone 2, AEx nA IIC T4 | |
| Class I, Zone 2, Ex nA IIC T4 Gc X | |
| Class I, Div. 2, Groups A, B, C, D |
Power supply
| Supply voltage range | 18 V DC … 30 V DC (Screw connection) |
|---|---|
| 18 V DC … 30 V DC (as an alternative or redundant, via backplane bus contact and system current supply) | |
| Typical current consumption | < 100 mA (24 V DC) |
| Protective circuit | Reverse polarity protection |
| Connection method | Plug-in screw terminal block (COMBICON), redundancy possible |
| Conductor cross section flexible max. | 2.50 mm² |
| Conductor cross section flexible min. | 0.20 mm² |
| Conductor cross section solid max. | 2.50 mm² |
| Conductor cross section solid min. | 0.20 mm² |
| Max. AWG conductor cross section, flexible | 14 |
| Min. AWG conductor cross section, flexible | 24 |
| Conductor cross section AWG max. | 14 |
| Conductor cross section AWG min. | 24 |
