Key Commercial Data
| Orderkey | 2891320 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 338 (C-6-2017) |
| GTIN | 4046356869614 |
| Weight per Piece (excluding packing) | 278.800 g |
| Custom tariff number | 85176200 |
| Country of origin | TW (Taiwan) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | 0 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | 0 °C … 70 °C |
| Permissible humidity (operation) | 5 % … 95 % (non-condensing) |
General
| Electrical isolation | VCC // FE // Ethernet |
|---|---|
| Latency | ± 1.3 µs (Store&Forward mode, 10/100 Mbps, depending on the frame size) |
| Test voltage data interface/power supply | 1500 V AC (500 V AC, 1 minute) |
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
| Mounting position | On horizontal DIN rail NS 35 in acc. with EN 60715 |
| Net weight | 278.8 g |
| Conformance | CE-compliant |
| UL, USA/Canada | Class I, Div. 2, Groups A, B, C, D |
Power supply
| Nominal supply voltage | 24 V DC |
|---|---|
| Supply voltage range | 12 V DC … 48 V DC |
| Typical current consumption | 73 mA (24 V DC) |
| Connection method | Plug-in/screw connection via COMBICON |
| Conductor cross section flexible max. | 2.50 mm² |
| Conductor cross section flexible min. | 0.20 mm² |
| Conductor cross section solid max. | 2.50 mm² |
| Conductor cross section solid min. | 0.20 mm² |
| Max. AWG conductor cross section, flexible | 12 |
| Min. AWG conductor cross section, flexible | 24 |
| Conductor cross section AWG max. | 12 |
| Conductor cross section AWG min. | 24 |
