Key Commercial Data
| Orderkey | 2313931 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 345 (C-6-2017) |
| GTIN | 4046356575089 |
| Weight per Piece (excluding packing) | 118.900 g |
| Custom tariff number | 85437090 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -25 °C … 75 °C |
|---|---|
| Ambient temperature (storage/transport) | -25 °C … 85 °C |
| Permissible humidity (operation) | 10 % … 95 % (non-condensing) |
| Permissible humidity (storage/transport) | 5 % … 95 % (non-condensing) |
| Altitude | 5000 m (For restrictions see manufacturer’s declaration) |
| Degree of protection | IP20 |
General
| Electrical isolation | Ethernet // Ethernet |
|---|---|
| Test voltage data interface/data interface | 4 kV AC (50 Hz, 1 min.) |
| Insulation voltage input/output | 250 Vrms |
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
| Net weight | 118.9 g |
| Housing material | PA 6.6-FR |
| Color | green |
| MTBF | 38062 Years (Telcordia standard, 25°C temperature, 21% operating cycle (5 days a week, 8 hours a day)) |
| 12264 Years (Telcordia standard, 40°C temperature, 34.25% operating cycle (5 days a week, 12 hours a day)) | |
| UL, USA/Canada | 508 Listed |
Serial interface
| Interface 1 | Ethernet interface, 10/100Base-T(X) in acc. with IEEE 802.3u |
|---|---|
| Interface | Ethernet |
| No. of ports | 1 |
| Connection method | RJ45 socket, shielded |
| Transmission length | ≤ 100 m (Total length across both ports (dependent on data rate and cable used)) |
| Serial transmission speed | 10/100 Mbps |
| Interface 2 | Ethernet interface, 10/100Base-T(X) in acc. with IEEE 802.3u |
| Interface | Ethernet |
| No. of ports | 1 |
| Connection method | RJ45 socket, shielded |
| Serial transmission speed | 10/100 Mbps |
Standards and Regulations
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
|---|---|
| Type of test | Vibration resistance in acc. with EN 60068-2-6/IEC 60068-2-6 |
| Test result | 5g, 10…150 Hz, 2.5 h, in XYZ direction |
| Type of test | Shock in acc. with EN 60068-2-27/IEC 60068-2-27 |
| Test result | 25g, 11 ms period, half-sine shock pulse |
| Standards/regulations | EN 61000-4-2 |
| Contact discharge | ± 6 kV (Test Level 3) |
| Standards/regulations | EN 61000-4-3 |
| Frequency range | 26 MHz … 3 GHz (Test Level 3) |
| Standards/regulations | EN 61000-4-4 |
| Comments | Criterion B |
| Standards/regulations | EN 61000-4-5 |
| Signal | ± 1 kV (Data line, asymmetrical) |
| Standards/regulations | EN 61000-6-4 |
| EN 61000-4-6 | |
| Frequency range | 0.15 MHz … 80 MHz |
| Standards/regulations | EN 50121 and EN 50155 (for railway applications) |
| UL, USA/Canada | 508 Listed |
| DNV GL-Temperature | B |
| DNV GL-Humidity | A |
| DNV GL-Vibration | A |
| DNV GL-EMC | B |
| DNV GL-Enclosure | Required protection according to the Rules shall be provided upon installation on board |
| Noxious gas test | ISA-S71.04-1985 G3 Harsh Group A |
