Key Commercial Data
| Orderkey | 2316050 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 512 (C-6-2017) |
| GTIN | 4055626000923 |
| Weight per Piece (excluding packing) | 111.700 g |
| Custom tariff number | 85389099 |
| Country of origin | US (United States) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -40 °C … 85 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Permissible humidity (operation) | 10 % … 95 % (non-condensing) |
| Degree of protection | IP20 |
General
| Mounting position | On horizontal DIN rail NS 35 in acc. with EN 60715 |
|---|---|
| Net weight | 111.7 g |
| Color | green |
| Conformance | CE-compliant, additionally EN 61326 |
| Fieldbus Foundation | FF-846 |
Power supply
| Supply voltage range | 10.5 V DC … 32 V DC (input on trunk line side) |
|---|---|
| Max. current consumption | 2 mA (with terminator) |
| Conductor cross section flexible max. | 0.20 mm² |
| Conductor cross section flexible min. | 2.50 mm² |
| Conductor cross section solid max. | 0.20 mm² |
| Conductor cross section solid min. | 2.50 mm² |
| Max. AWG conductor cross section, flexible | 12 |
| Min. AWG conductor cross section, flexible | 24 |
| Conductor cross section AWG max. | 12 |
| Conductor cross section AWG min. | 24 |
