Key Commercial Data
| Orderkey | 2316312 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 514 (C-6-2017) |
| GTIN | 4055626276991 |
| Weight per Piece (excluding packing) | 1,265.000 g |
| Custom tariff number | 85369095 |
| Country of origin | US (United States) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -40 °C … 80 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Permissible humidity (operation) | 95 % (non-condensing) |
| Degree of protection | IP20 |
| IP20, IP30 over trunk connections |
General
| Mounting position | On horizontal and vertical DIN rail NS 35 in acc. with EN 60715 |
|---|---|
| Net weight | 1265 g |
| Degree of pollution | 2 |
| Overvoltage category | II |
| Conformance | EMC 2014/30/EU |
| ATEX 2014/34/EU | |
| Fieldbus Foundation | FF-846 |
Power supply
| Supply voltage range | 16 V DC … 32 V DC (input on trunk line side) |
|---|---|
| Max. current consumption | 50 mA (trunk, no load) |
| 550 mA (maximum trunk current) | |
| Conductor cross section flexible max. | 0.20 mm² |
| Conductor cross section flexible min. | 2.50 mm² |
| Conductor cross section solid max. | 0.20 mm² |
| Conductor cross section solid min. | 2.50 mm² |
| Max. AWG conductor cross section, flexible | 12 |
| Min. AWG conductor cross section, flexible | 24 |
| Conductor cross section AWG max. | 12 |
| Conductor cross section AWG min. | 24 |
