Key Commercial Data
| Orderkey | 2867924 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 663 (IF-2009) |
| GTIN | 4046356046947 |
| Weight per Piece (excluding packing) | 140.340 g |
| Custom tariff number | 85364900 |
| Country of origin | AT (Austria) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -25 °C … 55 °C |
|---|---|
| -25 °C … 40 °C (corresponds to UL 508) | |
| Ambient temperature (storage/transport) | -25 °C … 70 °C |
| Permissible humidity (operation) | 15 % … 85 % |
| Noise immunity | EN 61000-6-2 |
Coil side
| Input voltage range | 24 V DC (see Power modules) |
|---|---|
| 24 V AC … 230 V AC (see Power modules) | |
| Temperature sensitivity | ≤ 0.01 %/K |
| Function | S: Star/delta startup |
| Time setting range | 500 ms … 3 min. (4 time end ranges) |
| Recovery time | 500 ms |
Contact side
| Contact type | 2 floating PDT contacts |
|---|---|
| Maximum switching voltage | 250 V AC (in acc. with IEC 60664-1) |
| Interrupting rating (ohmic load) max. | 750 VA (3 A/250 V AC, module aligned, ≤ 5 mm spacing) |
| 1250 VA (5 A/250 V AC, module not aligned, ≥ 5 mm spacing) | |
| Output fuse | 5 A (fast-blow) |
