Key Commercial Data
| Orderkey | 2866161 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 279 (C-5-2017) |
| GTIN | 4046356046596 |
| Weight per Piece (excluding packing) | 138.660 g |
| Custom tariff number | 85364900 |
| Country of origin | AT (Austria) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -25 °C … 55 °C |
|---|---|
| -25 °C … 40 °C (corresponds to UL 508) | |
| Ambient temperature (storage/transport) | -25 °C … 70 °C |
| Permissible humidity (operation) | 15 % … 85 % |
| Noise immunity | EN 61000-6-2 |
Coil side
| Input voltage range | 24 V DC … 240 V DC -20 % … +25 % |
|---|---|
| 24 V AC … 240 V AC -15 % … +10 % | |
| Temperature sensitivity | ≤ 0.01 %/K |
| Function | E: With switch-on delay |
| Rs: With release delay and control contact | |
| Es: With switch-on delay and control contact | |
| Wu: With single shot leading edge, voltage controlled | |
| Ws: With single shot leading edge and control contact | |
| Wa: With single shot trailing edge and control contact | |
| Bi: Flashing beginning with pulse | |
| Bp: Flashing beginning with pause | |
| Time setting range | 50 ms … 100 h (7 time end ranges) |
| Recovery time | 500 ms |
Contact side
| Contact type | 2 floating PDT contacts |
|---|---|
| Maximum switching voltage | 250 V AC (in acc. with IEC 60664-1) |
| Interrupting rating (ohmic load) max. | 750 VA (3 A/250 V AC, module aligned, ≤ 5 mm spacing) |
| 1250 VA (5 A/250 V AC, module not aligned, ≥ 5 mm spacing) | |
| Output fuse | 5 A (fast-blow) |
