Key Commercial Data
| Orderkey | 2907713 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 273 (C-5-2017) |
| GTIN | 4055626220758 |
| Weight per Piece (excluding packing) | 79.900 g |
| Custom tariff number | 85364900 |
| Country of origin | AT (Austria) |
Ambient conditions
| Ambient temperature (operation) | -25 °C … 55 °C |
|---|---|
| -25 °C … 40 °C (corresponds to UL 508) | |
| Ambient temperature (storage/transport) | -25 °C … 70 °C |
| Permissible humidity (operation) | 15 % … 85 % |
| Noise immunity | EN 61000-6-2 |
Coil side
| Input voltage range | 24 V AC/DC … 240 V AC/DC -10 % … +15 % |
|---|---|
| Temperature sensitivity | ≤ 0.01 %/K |
| Function | lp: Switched-mode beginning with the pause |
| li: Switched-mode beginning with the pulse | |
| Time setting range | 50 ms … 100 h (7 time end ranges) |
| Recovery time | 500 ms |
Contact side
| Contact type | 1 floating PDT |
|---|---|
| Maximum switching voltage | 250 V AC (in acc. with IEC 60664-1) |
| Interrupting rating (ohmic load) max. | 750 VA (3 A/250 V AC, module aligned, ≤ 5 mm spacing) |
| 1250 VA (5 A/250 V AC, module not aligned, ≥ 5 mm spacing) | |
| Output fuse | 5 A (fast-blow) |
General
| Status display | Green LED (POWER) |
|---|---|
| Yellow LED (relay active) | |
| Mechanical service life | approx. 2x 107cycles |
| Nominal power consumption | 2.5 VA (1 W) |
| Test voltage relay winding/relay contact | 4 kV |
| Mounting position | any |
| Assembly instructions | on standard DIN rail NS 35 in accordance with EN 60715 |
| Color | gray |
| Permissible humidity (operation) | 15 % … 85 % |
| Nominal frequency | 48 Hz … 63 Hz |
| Rated insulation voltage | 300 V (acc. to EN 50178) |
| Conformance | CE-compliant |
