Key Commercial Data
| Orderkey | 2905813 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 272 (C-5-2017) |
| GTIN | 4055626003351 |
| Weight per Piece (excluding packing) | 80.000 g |
| Custom tariff number | 85364900 |
| Country of origin | AT (Austria) |
Ambient conditions
| Ambient temperature (operation) | -25 °C … 55 °C |
|---|---|
| Ambient temperature (storage/transport) | -25 °C … 70 °C |
| Permissible humidity (operation) | 15 % … 85 % |
| Noise immunity | EN 61000-6-2 |
Coil side
| Input voltage range | 24 V AC/DC … 240 V AC/DC -15 % … +10 % |
|---|---|
| Temperature sensitivity | ≤ 0.01 %/K |
| Function | E: With switch-on delay |
| Rs: With release delay and control contact | |
| Es: With switch-on delay and control contact | |
| Ws: With single shot leading edge and control contact | |
| Time setting range | 50 ms … 1 h (5 time end ranges) |
| Recovery time | 100 ms |
Contact side
| Contact type | 1 floating PDT |
|---|---|
| Maximum switching voltage | 250 V AC (in acc. with IEC 60664-1) |
| Interrupting rating (ohmic load) max. | 1250 VA (5 A / 250 V AC) |
| Output fuse | 5 A (fast-blow) |
General
| Status display | Green LED (POWER) |
|---|---|
| Yellow LED (relay active) | |
| Mechanical service life | 15x 106cycles |
| Nominal power consumption | 4 VA |
| Test voltage relay winding/relay contact | 4 kV |
| Mounting position | any |
| Assembly instructions | on standard DIN rail NS 35 in accordance with EN 60715 |
| Color | gray |
| Permissible humidity (operation) | 15 % … 85 % |
| Nominal frequency | 48 Hz … 63 Hz |
| Conformance | CE-compliant |
| UL, USA/Canada | UL 508 Listed |
