Key Commercial Data
| Orderkey | 2943770 |
|---|---|
| Packing unit | 5 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4017918081324 |
| Weight per Piece (excluding packing) | 153.310 g |
| Custom tariff number | 85364190 |
| Country of origin | DE (Germany) |
Coil side
| Nominal input voltage UN | 24 V DC |
|---|---|
| Input voltage range in reference to UN | 0.8 … 1.1 |
| Typical input current at UN | 12 mA |
| Typical response time | 6 ms |
| Typical release time | 10 ms |
| Protective circuit | Damping diode, polarity protection Damping diode, polarity protection diode |
| Operating voltage display | yes |
| Power dissipation for nominal condition | 0.29 W |
Contact side
| Contact type | Single contact, 1 N/O contact |
|---|---|
| Type of switch contact | Single contact |
| Contact material | Silver cadmium oxide (AgCdO) |
| Maximum switching voltage | 250 V AC/DC |
| Maximum inrush current | 6 A |
| Limiting continuous current | 6 A |
| Interrupting rating (ohmic load) max. | 144 W (at 24 V DC) |
| 70 W (at 48 V DC) | |
| 55 W (at 60 V DC) | |
| 50 W (at 110 V DC) | |
| 50 W (at 220 V DC) | |
| 1500 VA (for 250 V AC) |
