Key Commercial Data
| Orderkey | 2942399 |
|---|---|
| Packing unit | 5 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4017918080716 |
| Weight per Piece (excluding packing) | 85.780 g |
| Custom tariff number | 85364190 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Coil side
| Nominal input voltage UN | 24 V DC |
|---|---|
| Input voltage range in reference to UN | 0.8 … 1.1 |
| Typical input current at UN | 12 mA |
| Typical response time | 7 ms |
| Typical release time | 8 ms |
| Protective circuit | Damping diode, polarity protection Damping diode, polarity protection diode, bridge rectifier at AC input |
| Operating voltage display | yes |
| Power dissipation for nominal condition | 0.29 W |
Contact side
| Contact type | Single contact, 1 N/O contact |
|---|---|
| Type of switch contact | Single contact |
| Contact material | Fine grained silver (AgNi 0,15), 5 µm hard gold-plated |
| Maximum switching voltage | 60 V AC/DC |
| Maximum inrush current | 0.2 A |
| Limiting continuous current | 2 A |
| Interrupting rating (ohmic load) max. | 5 W (at 24 V DC) |
| 10 W (at 48 V DC) | |
| 12 W (at 60 V DC) | |
| 12 VA (for 60 V AC) |
