Key Commercial Data
| Orderkey | 2952334 |
|---|---|
| Packing unit | 5 pc |
| Catalog page | Page 281 (C-5-2017) |
| GTIN | 4017918084431 |
| Weight per Piece (excluding packing) | 100.760 g |
| Custom tariff number | 85318070 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 45 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 60 °C |
General
| Input voltage | 24 V DC |
|---|---|
| Current required per light indicator | approx. 3 mA |
| Status display | 14 red LEDs and shared return line |
| Mounting position | any |
| Assembly instructions | In rows with zero spacing |
Connection data
| Conductor cross section solid min. | 0.2 mm² |
|---|---|
| Conductor cross section solid max. | 4 mm² |
| Conductor cross section flexible min. | 0.2 mm² |
| Conductor cross section flexible max. | 2.5 mm² |
| Conductor cross section AWG min. | 24 |
| Conductor cross section AWG max. | 12 |
| Stripping length | 8 mm |
| Screw thread | M3 |
| Connection method | Screw connection |
Environmental Product Compliance
| China RoHS | Environmentally Friendly Use Period = 50 |
|---|---|
| For details about hazardous substances go to tab “Downloads”, Category “Manufacturer’s declaration” |
