Key Commercial Data
| Orderkey | 2950116 |
|---|---|
| Packing unit | 5 pc |
| Catalog page | Page 280 (C-5-2017) |
| GTIN | 4017918083960 |
| Weight per Piece (excluding packing) | 88.560 g |
| Custom tariff number | 85411000 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 70 °C |
General
| Diode type | 1 N 4007 |
|---|---|
| Peak reverse voltage per diode | 1300 V |
| Reverse current per diode | 5 µA |
| Conducting state voltage per diode | approx. 0.8 V |
| Conducting state current per diode | 0.7 A (with single load) |
| 0.2 A (with simultaneous loads) | |
| Standards/specifications | DIN EN 50178 |
| Mounting position | any |
| Assembly instructions | In rows with zero spacing |
Connection data
| Conductor cross section solid min. | 0.2 mm² |
|---|---|
| Conductor cross section solid max. | 4 mm² |
| Conductor cross section flexible min. | 0.2 mm² |
| Conductor cross section flexible max. | 2.5 mm² |
| Conductor cross section AWG min. | 24 |
| Conductor cross section AWG max. | 12 |
| Stripping length | 8 mm |
| Screw thread | M3 |
| Connection method | Screw connection |
