Key Commercial Data
| Orderkey | 2952350 |
|---|---|
| Packing unit | 10 pc |
| Catalog page | Page 454 (C-5-2017) |
| GTIN | 4017918084455 |
| Weight per Piece (excluding packing) | 63.120 g |
| Custom tariff number | 85364190 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
Coil side
| Nominal input voltage UN | 24 V DC |
|---|---|
| Input voltage range in reference to UN | 0.9 … 1.1 |
| Nominal control voltage | 24 V DC |
| Minimum control voltage | 15 V DC |
| Maximum control voltage | 35 V DC |
| Minimum control current | 0.5 mA |
| Maximum control current | 1 mA |
| Typical input current at UN | 21 mA |
| Typical response time | 9 ms |
| Typical release time | 10 ms |
| Protective circuit | Reverse polarity protection Polarity protection diode |
| Free-wheeling diode Damping diode | |
| Operating voltage display | Yellow LED |
| Power dissipation for nominal condition | 0.5 W |
Contact side
| Contact type | Single contact, 1-PDT |
|---|---|
| Type of switch contact | Single contact |
| Contact material | AgNi |
| Maximum switching voltage | 250 V AC |
| 110 V DC | |
| Maximum inrush current | 8 A |
| Limiting continuous current | 5 A |
| Interrupting rating (ohmic load) max. | 120 W (at 24 V DC) |
| 60 W (at 48 V DC) | |
| 50 W (at 60 V DC) | |
| 50 W (at 110 V DC) | |
| 80 W (at 220 V DC) | |
| 1250 VA (for 250 V AC) |
