Key Commercial Data
| Orderkey | 2952910 |
|---|---|
| Packing unit | 10 pc |
| Catalog page | Page 145 (IF-2009) |
| GTIN | 4017918084509 |
| Weight per Piece (excluding packing) | 47.270 g |
| Custom tariff number | 85364190 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -40 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 70 °C |
Coil side
| Nominal input voltage UN | 24 V DC |
|---|---|
| Input voltage range in reference to UN | 0.8 … 1.1 |
| Typical input current at UN | typ. 8 mA |
| Typical response time | 5 ms |
| Typical release time | 5 ms |
| Coil voltage | 24 V DC |
| Protective circuit | Free-wheeling diode Damping diode |
| Reverse polarity protection Polarity protection diode | |
| Pulse time range | 30 ms … 5 s |
| Power dissipation for nominal condition | 0.19 W |
Contact side
| Contact type | Single contact, 1-PDT |
|---|---|
| Type of switch contact | Single contact |
| Contact material | AgSnO |
| Maximum switching voltage | 250 V AC/DC |
| Minimum switching voltage | 5 V (at 100 mA) |
| 24 V (At 1 mA) | |
| Min. switching current | 1 mA (at 24 V) |
| 100 mA (At 5 V) | |
| Maximum inrush current | 8 A |
| Limiting continuous current | 6 A |
| Interrupting rating (ohmic load) max. | 144 W (at 24 V DC) |
| 43 W (at 48 V DC) | |
| 42 W (at 60 V DC) | |
| 55 W (at 110 V DC) | |
| 100 W (at 220 V DC) | |
| 1500 VA (for 250 V AC) |
