Key Commercial Data
| Orderkey | 2940430 |
|---|---|
| Packing unit | 10 pc |
| Catalog page | Page 135 (IF-2011) |
| GTIN | 4017918080105 |
| Weight per Piece (excluding packing) | 50.300 g |
| Custom tariff number | 85364900 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 40 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
Coil side
| Nominal input voltage UN | 230 V AC |
|---|---|
| Input voltage range in reference to UN | 0.85 … 1.1 |
| Mains frequency | 50/60 Hz |
| Typical input current at UN | 4 mA |
| Typical response time | 7 ms |
| 3 ms … 12 ms | |
| Typical release time | 3 ms |
| Typical release time range | 2 ms … 9 ms |
| Operating voltage display | Glow lamp |
| Power dissipation for nominal condition | 0.92 W |
Contact side
| Contact type | Single contact, 2-PDT |
|---|---|
| Type of switch contact | Single contact |
| Contact material | AgNi |
| Maximum switching voltage | 250 V AC/DC |
| Maximum inrush current | 6 A |
| Limiting continuous current | 5 A |
| Interrupting rating (ohmic load) max. | 120 W (at 24 V DC) |
| 95 W (at 48 V DC) | |
| 60 W (at 60 V DC) | |
| 40 W (at 110 V DC) | |
| 55 W (at 220 V DC) | |
| 1250 VA (for 250 V AC) |
