Key Commercial Data
| Orderkey | 2949994 |
|---|---|
| Packing unit | 10 pc |
| Catalog page | Page 447 (C-5-2017) |
| GTIN | 4017918083915 |
| Weight per Piece (excluding packing) | 47.400 g |
| Custom tariff number | 85364190 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
Coil side
| Nominal input voltage UN | 24 V DC |
|---|---|
| Input voltage range in reference to UN | 0.85 … 1.1 |
| Typical input current at UN | 28 mA |
| Typical response time | 13 ms |
| Typical release time | 15 ms |
| Protective circuit | Free-wheeling diode Damping diode |
| Operating voltage display | Yellow LED |
| Power dissipation for nominal condition | 0.67 W |
Contact side
| Contact type | 1 N/O contact with lead contact |
|---|---|
| Type of switch contact | Lead contact |
| Contact material | AgSnO2 |
| Note | Main contact silver tin oxide (AgSnO2): lead contact tungsten |
| Maximum switching voltage | 250 V AC |
| Maximum inrush current | 80 A (20 ms) |
| Limiting continuous current | 10 A |
| Interrupting rating (ohmic load) max. | 2500 VA (for 250 V AC) |
