Key Commercial Data
| Orderkey | 2866093 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 271 (C-5-2017) |
| GTIN | 4017918952716 |
| Weight per Piece (excluding packing) | 142.700 g |
| Custom tariff number | 85364900 |
| Country of origin | AT (Austria) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -25 °C … 55 °C |
|---|---|
| -25 °C … 40 °C (corresponds to UL 508) | |
| Ambient temperature (storage/transport) | -25 °C … 70 °C |
Input data
| Maximum temperature coefficient | < 0.1 %/K |
|---|---|
| Function | Winding temperature monitoring |
| Basic accuracy | ± 10 % (of scale end value) |
| Repeat accuracy | ≤ 2 % |
| Total cold resistance | < 1.5 kΩ |
| Response value | ≥ 3.6 kΩ (Relay drops out) |
| Release value | ≤ 1.8 kΩ (Relay picks up) |
| Short-circuit detection | < 20 Ω |
| Voltage influence | ≤ 1 % |
| Recovery time | 500 ms |
Contact side
| Contact type | 2 floating PDT contacts |
|---|---|
| Maximum switching voltage | 250 V AC (in acc. with IEC 60664-1) |
| Interrupting rating (ohmic load) max. | 750 VA (3 A/250 V AC, module aligned, ≤ 5 mm spacing) |
| 1250 VA (5 A/250 V AC, module not aligned, ≥ 5 mm spacing) | |
| Output fuse | 5 A (fast-blow) |
