Key Commercial Data
| Orderkey | 2885773 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 268 (C-5-2017) |
| GTIN | 4046356100786 |
| Weight per Piece (excluding packing) | 164.900 g |
| Custom tariff number | 85364900 |
| Country of origin | AT (Austria) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -25 °C … 55 °C |
|---|---|
| -25 °C … 40 °C (corresponds to UL 508) | |
| Ambient temperature (storage/transport) | -25 °C … 70 °C |
Input data
| Nominal input voltage UN | 3 N ~ 230/132 V |
|---|---|
| Maximum temperature coefficient | < 0.1 %/K |
| Function | Undervoltage, window, asymmetry, phase sequence, phase failure |
| Min. setting range | -30 % … 20 % (From UN) |
| Max. setting range | -20 % … 30 % (From UN) |
| Min setting range of the voltage threshold value | 161 V AC … 276 V AC |
| Max. setting range of the voltage threshold value | 184 V AC … 299 V AC |
| Setting range for response delay | 0.1 s … 10 s |
| Basic accuracy | ± 5 % (of scale end value) |
| Setting accuracy | ≤ 5 % (of scale end value) |
| Repeat accuracy | ≤ 2 % |
| Asymmetry | 5 % … 25% / OFF |
| Recovery time | 500 ms |
Contact side
| Contact type | 2 floating PDT contacts |
|---|---|
| Maximum switching voltage | 250 V AC (in acc. with IEC 60664-1) |
| Interrupting rating (ohmic load) max. | 750 VA (3 A/250 V AC, module aligned, ≤ 5 mm spacing) |
| 1250 VA (5 A/250 V AC, module not aligned, ≥ 5 mm spacing) | |
| Output fuse | 5 A (fast-blow) |
