Key Commercial Data
| Orderkey | 2903523 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 262 (C-5-2017) |
| GTIN | 4046356747271 |
| Weight per Piece (excluding packing) | 79.800 g |
| Custom tariff number | 85364900 |
| Country of origin | AT (Austria) |
Ambient conditions
| Ambient temperature (operation) | -25 °C … 55 °C |
|---|---|
| Ambient temperature (storage/transport) | -25 °C … 70 °C |
Connection data
| Connection method | Screw connection |
|---|---|
| Conductor cross section solid min. | 0.5 mm² |
| Conductor cross section solid max. | 2.5 mm² |
| Conductor cross section AWG min. | 20 |
| Conductor cross section AWG max. | 14 |
| Conductor cross section flexible min. | 0.5 mm² |
| Conductor cross section flexible max. | 2.5 mm² |
| Stripping length | 8 mm |
General
| Status display | Yellow LED |
|---|---|
| Overvoltage category | III, 300 V basic insulation (DIN EN 60947-5-1) |
| Rated insulation voltage | 300 V (Supply circuit/measuring circuit (DIN EN 60947-5-1)) |
| Electromagnetic compatibility | Conformance with EMC Directive 2004/108/EC |
| Noise emission | EN 61000-6-3 |
| Noise immunity | EN 61000-6-2 |
| Color | gray |
| Mounting position | any |
| Assembly instructions | on standard DIN rail NS 35 in accordance with EN 60715 |
| Conformance | CE-compliant |
| UL, USA/Canada | UL/C-UL listed UL 508 |
Standards and Regulations
| Electromagnetic compatibility | Conformance with EMC Directive 2004/108/EC |
|---|---|
| Noise emission | EN 61000-6-3 |
| Noise immunity | EN 61000-6-2 |
| Low Voltage Directive | Conformance with LV directive 2006/95/EC |
| Conformance | CE-compliant |
| UL, USA/Canada | UL/C-UL listed UL 508 |
