Key Commercial Data
| Orderkey | 2964173 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 190 (IF-2011) |
| GTIN | 4017918099381 |
| Weight per Piece (excluding packing) | 651.120 g |
| Custom tariff number | 85364900 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
| Degree of protection | IP20 |
Input data
| Input name | Control input right/left |
|---|---|
| Quiescent current | 40 mA |
| Rated actuating voltage UC | 24 V DC |
| Triggering voltage range | 19.2 V DC … 30 V DC |
| Voltage range with reference to UC | 0.8 … 1.25 |
| Rated actuating current IC | 7.5 mA |
| Reaction time in normal load operation | 50 ms |
| Switch-over frequency | < 10 Hz (At cos φ > 0.5) |
| Protective circuit | Reverse polarity protection Polarity protection diode |
| Surge protection | |
| Operating voltage display | Green LED |
| Status display | Yellow LED |
| Indication | Red LED |
| Maximum reversing frequency | 10 Hz |
| Switchover time RL/LL(turn-on time) | 20 ms |
Output data load output
| Output name | AC output |
|---|---|
| Rated operating voltage Ue | 400 V AC |
| Operating voltage range | 110 V AC … 440 V AC |
| Load current range | 150 mA |
| Leakage current | typ. 7 mA |
| Residual voltage | typ. 1.5 V |
| Surge current | 230 A (tp = 10 ms, at 25 °C) |
| Type of protection | RC element |
| Protective circuit/component | RC element |
| Type of protection | Surge protection |
