Key Commercial Data
| Orderkey | 2964555 |
|---|---|
| Packing unit | 10 pc |
| Catalog page | Page 451 (C-5-2017) |
| GTIN | 4017918130992 |
| Weight per Piece (excluding packing) | 21.700 g |
| Custom tariff number | 85364190 |
| Country of origin | CN (China) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
Input data
| Nominal input voltage UN | 5 V DC |
|---|---|
| Input voltage range in reference to UN | 0.5 … 1.2 |
| Input voltage range | 2.5 V DC … 6 V DC |
| Switching threshold “0” signal in reference to UN | ≤ 0.3 |
| Switching threshold “1” signal in reference to UN | ≥ 0.5 |
| Typical input current at UN | 8 mA |
| Typical response time | 1 µs |
| Typical turn-off time | 2 µs |
| Operating voltage display | Yellow LED |
| Type of protection | Reverse polarity protection |
| Surge protection | |
| Protective circuit/component | Polarity protection diode |
| Transmission frequency | 100 kHz |
Output data
| Output voltage range | 14 V DC … 30 V DC |
|---|---|
| Limiting continuous current | 50 mA |
| Quiescent current | 15 mA |
| Voltage drop at max. limiting continuous current | ≤ 2.2 V DC |
| Output circuit | 3-conductor push-pull, ground referenced |
| Type of protection | Surge protection |
| Protective circuit/component | Suppressor diode |
