Key Commercial Data
| Orderkey | 1421126 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 377 (C-2-2017) |
| GTIN | 4055626254654 |
| Weight per Piece (excluding packing) | 29.000 g |
| Custom tariff number | 85366990 |
| Country of origin | PL (Poland) |
Mechanical characteristics
| Number of positions | 8 |
|---|---|
| Connection profile | RJ45 |
| Insertion/withdrawal cycles | ≥ 750 |
| Connection method | IDC fast connection |
| Conductor cross section | 0.23 mm² … 0.32 mm² (solid) |
| 0.23 mm² … 0.36 mm² (flexible) | |
| Connection cross section AWG | 23 … 22 (solid) |
| 23 … 22 (flexible) | |
| Max. cable diameter | 5 mm … 9 mm |
| External cable diameter | 5 mm … 9 mm |
| Cable outlet | straight |
| Wire diameter including insulation | ≤ 1.6 mm |
| Degree of protection | IP20 |
| Type | RJ45, IP20 |
| No. of cable outlets | 1 |
Material data
| Flammability rating according to UL 94 | V0 |
|---|---|
| Housing material | Zinc die-cast |
| Contact carrier material | PC |
| Contact material | Copper alloy |
| Contact surface material | Gold over nickel |
Electrical characteristics
| Number of positions | 8 |
|---|---|
| Transmission speed | 1 Gbps |
| Transmission characteristics (category) | CAT5 (IEC 11801:2002) |
| GRP transmission properties | CAT5 (IEC 11801:2002) CAT5 (IEC 11801:2002) |
| Transmission speed | 1 Gbps |
| Frequency range | to 100 MHz |
| Rated current | 1.75 A |
| Overvoltage category | I |
| Contact resistance | 0.001 Ω (Wire – IDC) |
| 0.005 Ω (Litz wires – IDC) | |
| Rated voltage (III/3) | 72 V (DC) |
