A variety of fittings for suction cups.
General
Material
PA, AL, CUZN, NBR
Noise level
55 – 61 dBA
Temperature
14 – 176 °F
Weight
1.59 oz
Feed pressure, max.
101.5 psi
| Feed pressure | Air consumption | Vacuum flow (scfm) at different vacuum levels (-inHg) | Max vacuum | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| psi | scfm | 0 | 2 | 5 | 8 | 11 | 14 | 17 | 20 | 23 | 26 | -inHg |
| 72.5 | 0.28 | 0.49 | 0.32 | 0.17 | 0.093 | 0.076 | 0.064 | 0.049 | 0.028 | 0.015 | 0 | 26.87 |
| Feed pressure | Air consumption | Evacuation time (s/cf) to reach different vacuum levels (-inHg) | Max vacuum | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| psi | scfm | 2 | 5 | 8 | 11 | 14 | 17 | 20 | 23 | 26 | -inHg |
| 72.5 | 3.68 | 14.72 | 39.36 | 85.23 | 156.026 | 242.39 | 348.86 | 503.19 | 778.15 | 0 | 26.87 |
