Key Commercial Data
| Orderkey | 3071401 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 623 (C-1-2017) |
| GTIN | 4055626289175 |
| Weight per Piece (excluding packing) | 429.700 g |
| Custom tariff number | 39259020 |
| Country of origin | PL (Poland) |
General
| Note | Cable binders can be used up to a width of 4 mm and from a length of 40 mm |
|---|---|
| Color | gray |
| Material | PC |
| Flammability rating according to UL 94 | V0 |
| Number of cables | 100 for 1.5 mm² |
| Cable feed-through | Cables can be pulled through at an angle between 120° and 180°. |
| Conductors up to 22 mm in diameter can be fed in. | |
| Components | halogen-free |
| Result of thermal test | Test passed |
| Proof of thermal characteristics (needle flame) effective duration | 30 s |
| Relative insulation material temperature index (Elec., UL 746 B) | 130 °C |
| Static insulating material application in cold | -40 °C |
| Fire protection for rail vehicles (DIN EN 45545-2) R22 | HL 1 – HL 3 |
| Fire protection for rail vehicles (DIN EN 45545-2) R23 | HL 1 – HL 3 |
| Fire protection for rail vehicles (DIN EN 45545-2) R24 | HL 1 – HL 3 |
Dimensions
| Width | 68 mm |
|---|---|
| Length | 218 mm |
| Height | 140.5 mm |
| Diameter | 42 mm |
| Hole diameter | 5.5 mm |
| Marking field | 36,8 x 27,2 mm |
| Cable length | 700 mm … 460 mm |
Standards and Regulations
| Flammability rating according to UL 94 | V0 |
|---|---|
| Fire protection for rail vehicles (DIN EN 45545-2) R22 | HL 1 – HL 3 |
| Fire protection for rail vehicles (DIN EN 45545-2) R23 | HL 1 – HL 3 |
| Fire protection for rail vehicles (DIN EN 45545-2) R24 | HL 1 – HL 3 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
