Key Commercial Data
| Orderkey | 2909713 |
|---|---|
| Packing unit | 1 pc |
| Minimum order quantity | 10 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4055626682426 |
| Weight per Piece (excluding packing) | 0.000 g |
| Custom tariff number | 85444290 |
| Country of origin | US (United States) |
General
| Nominal voltage UN | 125 V AC |
|---|---|
| 125 V DC | |
| Max. current carrying capacity per path | 1 A |
| Max. conductor resistance | ≤ 0.06 Ω/m |
| Length of cable | 15 m |
| Single wire, cross section | 0.36 mm² |
| Single wire, cross section [AWG] | 22 |
| External diameter | 12.3 mm |
| Shielding | yes |
| Overall foil shield |
Environmental conditions
| Ambient temperature (operation) | -20 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
Color code
| Connector 1 = connector 2 (optional) = wire color | D-SUB37 (1) = black |
|---|---|
| D-SUB37 (2) = red | |
| D-SUB37 (3) = black | |
| D-SUB37 (4) = white | |
| D-SUB37 (5) = black | |
| D-SUB37 (6) = green | |
| D-SUB37 (7) = black | |
| D-SUB37 (8) = blue | |
| D-SUB37 (9) = black | |
| D-SUB37 (10) = yellow | |
| D-SUB37 (11) = black | |
| D-SUB37 (12) = brown | |
| D-SUB37 (13) = black | |
| D-SUB37 (14) = orange | |
| D-SUB37 (15) = red | |
| D-SUB37 (16) = white | |
| D-SUB37 (17) = red | |
| D-SUB37 (18) = green | |
| D-SUB37 (19) = red | |
| D-SUB37 (20) = blue | |
| D-SUB37 (21) = red | |
| D-SUB37 (22) = yellow | |
| D-SUB37 (23) = red | |
| D-SUB37 (24) = brown | |
| D-SUB37 (25) = red | |
| D-SUB37 (26) = orange | |
| D-SUB37 (27) = green | |
| D-SUB37 (28) = white | |
| D-SUB37 (29) = green | |
| D-SUB37 (30) = blue | |
| D-SUB37 (31) = green | |
| D-SUB37 (32) = yellow | |
| D-SUB37 (33) = green | |
| D-SUB37 (34) = brown | |
| D-SUB37 (35) = green | |
| D-SUB37 (36) = orange | |
| D-SUB37 (37) = white |
