Key Commercial Data
| Orderkey | 2701508 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 203 (C-6-2017) |
| GTIN | 4046356763608 |
| Weight per Piece (excluding packing) | 710.000 g |
| Custom tariff number | 85176200 |
| Country of origin | DE (Germany) |
Dimensions
| Dimensional drawing | |
|---|---|
| Width | 60 mm |
| Height | 185 mm |
| Depth | 38 mm |
| Note on dimensions | The height is 194.5 mm including the mounting plate. With fixing clips pulled out, the height is 212 mm. The depth is 38 mm including the mounting plate (30.5 mm without the mounting plate). |
| Drill hole spacing | 198.5 mm |
Ambient conditions
| Ambient temperature (operation) | -25 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -25 °C … 85 °C |
| Permissible humidity (operation) | 5 % … 95 % |
| Permissible humidity (storage/transport) | 5 % … 95 % |
| Air pressure (operation) | 70 kPa … 106 kPa (up to 3000 m above sea level) |
| Air pressure (storage/transport) | 70 kPa … 106 kPa (up to 3000 m above sea level) |
| Degree of protection | IP65/IP67 |
General
| Housing material | Zinc die-cast |
|---|---|
| Mounting type | Wall mounting or DIN rail mounting; both with mounting plate. |
| Net weight | 710 g |
Interfaces
| Designation | PROFIBUS DP |
|---|---|
| No. of channels | 2 |
| Connection method | M12 fast connection technology |
| Note on the connection method | B-coded |
| Designation connection point | Copper cable |
| Transmission speed | 9.6 kbps … 12 Mbps (Automatic baud rate detection) |
| Transmission physics | PROFIBUS-DP-compliant copper cable |
| Address area assignment | 1 … 126, adjustable |
| Number of positions | 5 |
