Key Commercial Data
| Orderkey | 2700275 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 204 (C-6-2017) |
| GTIN | 4046356782586 |
| Weight per Piece (excluding packing) | 34.000 g |
| Custom tariff number | 85176200 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -25 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -25 °C … 85 °C |
| Permissible humidity (operation) | 5 % … 95 % |
| Permissible humidity (storage/transport) | 5 % … 95 % |
| Air pressure (operation) | 70 kPa … 106 kPa (up to 3000 m above sea level) |
| Air pressure (storage/transport) | 70 kPa … 106 kPa (up to 3000 m above sea level) |
| Degree of protection | IP65/IP67 |
General
| Net weight | 34 g |
|---|---|
| Degree of pollution | 2 |
| Diagnostics messages | Overrange or underrange Message in the diagnostic code (in the IB IL format) |
| Measured value invalid/no valid measured value present Message in the diagnostic code (in the IB IL format) | |
| Short circuit Message in the diagnostic code (in the IB IL format) | |
| Open circuit; goes to 0 mA Message in the diagnostic code (in the IB IL format) | |
| Module faulty Message in the diagnostic code (in the IB IL format) |
Standards and Regulations
| Mechanical tests | Vibration resistance in acc. with EN 60068-2-6/IEC 60068-2-6 Operation: 2g |
|---|---|
| Vibration resistance in acc. with EN 60068-2-6/IEC 60068-2-6 Storage/transport: 5g | |
| Shock in acc. with EN 60068-2-27/IEC 60068-2-27 Operation: 30g, 11 ms, three shocks in each space direction | |
| Shock in acc. with EN 60068-2-27/IEC 60068-2-27 Storage/transport: 50g, 11 ms, three shocks in each space direction | |
| Continuous shock according to EN 60068-2-27/IEC 60068-2-27 10g, 16 ms, 1000 shocks, in all space directions | |
| Protection class | III, IEC 61140, EN 61140, VDE 0140-1 |
