Key Commercial Data
| Orderkey | 2404701 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4055626426310 |
| Weight per Piece (excluding packing) | 225.600 g |
| Custom tariff number | 85371091 |
| Country of origin | DE (Germany) |
Ambient conditions
| Degree of protection | IP20 |
|---|---|
| Ambient temperature (operation) | -25 °C … 60 °C up to 2000 m above mean sea level |
| -25 °C … 55 °C up to 3000 m above mean sea level | |
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Permissible humidity (operation) | 10 % … 95 % (according to DIN EN 61131-2, non-condensing, no ice formation) |
| Permissible humidity (storage/transport) | 10 % … 95 % (according to DIN EN 61131-2, non-condensing, no ice formation) |
| Air pressure (operation) | 70 kPa … 106 kPa (up to 3000 m above sea level) |
| Air pressure (storage/transport) | 58 kPa … 106 kPa (up to 4500 m above mean sea level) |
| Shock | 30g, 11 ms period, half-sine shock pulse, according to IEC 60068-2-27 |
| Vibration (operation) | 5g |
Control system
| Engineering tool | PLCnext Engineer |
|---|---|
| Programming languages supported | Programming in acc. with IEC 61131-3 |
| Configuration tool | Config+ Version 1.01 or later |
IEC 61131 runtime system
| Engineering tool | PLCnext Engineer |
|---|---|
| Program memory | 2 Mbyte |
| Mass storage | 2 Mbyte |
| Retentive mass storage | 48 kByte (NVRAM) |
| Number of control tasks | 8 |
| Realtime clock | Yes |
Fieldbus function
| Designation | |
|---|---|
| Amount of process data | max. 4096 Bit (Axioline F local bus (input)) |
| max. 4096 Bit (Axioline F local bus (output)) | |
| max. 32768 Bit (per station) | |
| Number of supported devices | max. 63 (per station) |
| Number of local bus devices that can be connected | max. 63 (observe current consumption) |
